As a flexible distributor, we source and supply a range of passenger lifts from any number of suppliers. We are able to provide a selection of Traction and Hydraulic driven lifts with or without motor rooms. We also offer our own range of lift car finishes, however; we also provide a custom finish to add a personal touch. This ensures the requirements of our customers are always met.

As an option, we can tailor your lift car finishes to compliment the colour and design elements of your building. An example would be to match the lift car floor to the lobby floor.

Please note. For disabled access, the minimum lift car dimensions, in order to comply with current regulations are 1100mm wide x 1400mm deep. This would typically be an 8 person (630kg) car.



Passenger lifts

GENERAL SPECIFICATION

Load/Capacity:
Speed:
Maximum Travel:
Maximum Floors:
Entrances:

Drive System​:
Controller:
Door type:
Clear Door Opening:
Door Height​:
Car Dimensions:
Internal Car Height:

320kg to 1600kg/4 person – 21 person
0.6 – 1.6 m/s
Up to 75 metres
2 – 32 Floors
Single entry – Front only /Through entry – Front & Back
Direct Gearless or Hydraulic
Modern, low energy microprocessor
Automatic side/centre opening
From 600mm to 1600mm (in 100mm increments)
2000mm – 2100mm
Standard Car Dimension
2100mm – 2300mm





Passenger lift 2_470
